Vibration Attenuation Handheld Hydraulic Breaker Impact Frequency 1500-2400rbm

Ask Lasest Price
Brand Name :	Zondar
Model Number :	ZDHB30
Certification :	CE
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	5000sets/years
Delivery Time :	7-15workday

Add to Cart

Product Details
Company Profile

Vibration Attenuation Handheld Hydraulic Breaker Impact Frequency 1500-2400rbm

Hydraulic Breaker 30 Vibration Attenuation Handle Impact Frequency 1500-2400rbm

Hydraulic Break

Product descripition:

Hydraulic crushing pick is suitable for crushing solid reinforced concrete, rock, asphalt and ramming work.

Product features:

1. With strong crushing force and stable operation, the working efficiency of hand-held crushing picks is the highest among all hand-held picks, and its working noise is much smaller than that of pneumatic tools.

2. The internal parts of the hydraulic breaker run in hydraulic oil, with little wear, long working life and simple daily maintenance.

performance technology parameter configuration

Model	ZDHB10	ZDHB20	ZBHB30
Weight/kg	9.9	22	28
Flow/Lpm	18-23	26-34	26-34
Impact frequency/1/min	1500-2400	1500-2400	1500-2400
Maximum pressure/Mpa	16	16	16
Working pressure/Mpa	9-14	9-14	9-14
Pick-rod socket size/mm	19×50	25×108	25×108
Handle type	D-Handle	Anti-Vibration	328×328×470
Dimension/mm	550×235×75	660×470×132	680×410×140

Vibration Attenuation Handheld Hydraulic Breaker Impact Frequency 1500-2400rbm
